A RUD ACP-TURNADO swivel lifting point with metric coarse thread, featuring automatic load alignment, 360° rotation, and smart design, built for secure lifting in demanding industrial environments.

ACP-TURNADO / Metric coarse thread

Rud
$158.00 - $2,926.00
(No reviews yet)
Weight:
0.36 KGS
Current Stock:
Adding to cart… The item has been added
Description

Description

The RUD ACP-TURNADO (Metric Coarse Thread) is a revolutionary self-aligning swivel lifting point that sets a new standard in safety and efficiency. Unlike traditional eye bolts, the ACP-TURNADO automatically rotates into the optimal load direction under tension, preventing dangerous side loading and dramatically reducing the risk of lifting failure.

Featuring a 360° rotatable body and a 180° pivoting lifting ring, the ACP-TURNADO offers ultimate flexibility and ensures your load is lifted smoothly, safely, and efficiently—every time. Engineered by RUD, it is forged from high-tensile steel and equipped with a spring mechanism that ensures perfect positioning before and during the lift.

Features

  • Metric coarse thread – compatible with standard tapped holes

  • Auto-aligning design – the ring turns automatically into the load direction

  • 360° rotation + 180° pivot – full range of motion for dynamic lifts

  • Forged high-strength steel – designed for high-load and repetitive use

  • Built-in spring mechanism – prevents side pull and enhances safety

  • Clearly marked with WLL and batch number – for traceability

  • Compact, visible design – powder-coated in RUD’s signature pink for durability and visibility

  • No need for manual adjustment – the safest swivel lifting point in its class

Applications

  • Heavy machinery and equipment lifting – perfect for dynamic or misaligned loads

  • Steel fabrication and transport – ideal for components with complex shapes or load angles

  • Rigging and construction – reduces operator error and improves lift safety

  • Maintenance and installation tasks – simplifies lifting of offset or rotating items

  • Manufacturing and assembly lines – excellent for frequent and repeat lifts

Why Choose the RUD ACP-TURNADO?

  • Automatically aligns with the load – eliminates dangerous side loading

  • Unmatched safety – spring-loaded mechanism improves control and reduces risk

  • Easy to install – standard metric coarse thread for quick integration

  • Smart lifting innovation – trusted RUD quality with industry-first safety features

Order Online at WA Lifting Equipment

The RUD ACP-TURNADO (Metric Coarse Thread) is the ultimate innovation in lifting point safety and performance. For smart, self-aligning, and ultra-safe lifting—order now from WA Lifting Equipment.

Type weight [kg] A [mm] B [mm] C [mm] D [mm] E [mm] F [mm] Fmax [mm] G [mm] H [mm] K [mm] L [mm] Lmax [mm] M N [mm] J [mm] T [mm] torque [Nm] Ref.-No. with bolt Ref.-No. without bolt
ACP M12 0.37 -- 11 10.5 38 30 19 117 28 54.5 58 47 145 M12 8 19 83 80 7909314 8600632
ACP M16 0.82 -- 14 14 50 40 22 149 36 68 76 58 185 M16 10 24 107 150 7909316 8600634
ACP M20 1.34 17 17.25 15 50 45 26.5 186.5 43.5 82.5 89 70 230 M20 12 30 118 250 7909317 8600636
ACP M24 3.03 23 23 23 64 64 41.5 210 55 104 121 89 265 M24 14 36 154 500 7909318 8600638
ACP M30 5.66 -- 29 27 75 75 41.5 271.5 68.5 129 148 110 340 M30 17 46 183 800 7909319 8600640
ACP M36 7.1 106 32 32 82 70 45 290 60 136 168 113 350 M36 22 65 189 1200 7911052 8600642
ACP M42 7.5 106 32 32 82 70 53 290 60 136 168 113 350 M42 24 65 189 1500 7911053 8600644
