Specifications
Your load just got lighter.
- Load distributor may be turned by 180° once the elimination criteria have been reached, thereby doubling its lifespan!
- The system is used for assembling IV-leg chain slings with Connex connecting links
- Where required, all four legs may be considered load-carrying
- If two II-leg slings are used at the same time and one of them is provided with a load distributor, this system can be treated as a IV-leg sling with four load-carrying legs
Specification table
| Code | Connecting link | Working load limit | Working load limit | Difference L1/L2 | |
|---|---|---|---|---|---|
| 0°-45° | 45°-60° | [chain links] | |||
| [kg] | [kg] | ||||
| AGWW 5/6 /O LOAD DISTRIBUTOR G10 PC/O | CW 8 | 2000 | 1400 | 6 for 5 mm chain/ 5 for 6 mm chain | |
| AGWW 7/8 /Z LOAD DISTRIBUTOR PC/O | CW 10 | 3550 | 2500 | 6 for 7 mm chain/ 5 for 8 mm chain | |
| AGWW 10 /Z LOAD DISTRIBUTOR PC/O | CW 13 | 5600 | 4000 | 4 | |
| AGWW 13 /Z LOAD DISTRIBUTOR PC/O | CW 16 | 9500 | 6700 | 4 | |
| AGWW 16 /Z LOAD DISTRIBUTOR PC/O | CW 19/20 | 14000 | 10000 | 4 | |
| AGWW 19/20 /O LOAD DISTR. G10 PC/O | CW 32 | 20000 | 14000 | 5 | |
| AGWW 22 /O LOAD DISTR. G10 PC/O | CW 32 | 26500 | 19000 | 5 | |
| AGWW 26 /O LOAD DISTRIBUTOR G10 PC/O | GSCHW VB G-4163 WLL 55 t | 37500 | 26500 | 5 | |
