FW 32 G10 Eye Foundry Hook

This hook comes with an extra-wide jaw and is used in applications where other hooks simply aren’t up to the job.

Jaw size matters.

Frequently used in foundries and also does an excellent job when used with Connex and welded systems
Manufactured according to EN 1677-1 with the mechanical values of G10 and comes with a full operating manual
CE-marking and BG-approval ensure quality of the highest

Code	Working load limit	e	h	a	d1	d2	g	b	Weight
	[kg]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[kg/pc.]
FW 7/8	2500	131	29	25	24	11	64	118	0,94
FW 10	4000	158	35	32	31	14	76	143	1,62
FW 13	6700	190	42	40	39	17	89	170	3,24
FW 16	10000	224	50	46	47	22	102	200	5,65
FW 19/20	16000	260	61	54	56	28	114	231	9,2
F 22	15000	265	70	61	47	30	127	260	9,31
FW 22	19000	287	75	63	47	31	140	284	13,4
F 26	21200	305	80	72	54	34	136	280	19,21
FW 26	26500	358	84	73	82	38	152	312	21,4
F 32	31500	327	93	83	60	37	152	336	28
FW 32	40000	370	101	90	66	44	170	359	35
