Specifications
Safety first.
- Complies with EN 1677-3 and rated for G12 load capacity, ensuring high performance and safety in lifting operations
- Automatically closes and locks under load, preventing unintentional opening and enhancing operational safety
- Larger jaw opening than the HSWP eye sling hook allows for more flexible use with the pewag winner pro Connex system
- Light blue powder-coated surface for corrosion resistance and visual identification
- Can only be opened when not under load, providing additional protection during use
- Locking set with lever, safety pin, and stainless spring is available as a spare parts kit and can be replaced easily by qualified personnel
- Certified with BG-approval, verifying safety through independent testing
Specification table
| Code | Working load limit (kg) | e (mm) | h (mm) | a (mm) | b (mm) | d1 (mm) | d2 (mm) | g1 (mm) | s max. (mm) | Weight (kg/pc.) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
LHWP 7/8 | 3000 | 126 | 25 | 25 | 89 | 25 | 14 | 34 | 1 | 0.91 |
| LHWP 10 | 5000 | 158 | 31 | 28 | 112 | 31 | 17 | 45 | 1.5 | 1.56 | |
| LHWP 13 | 8000 | 205 | 41 | 34 | 145 | 40 | 22 | 54 | 2 | 3.5 |
