PLGWI 2T Supreme M20 Stainless Steel Lifting Point

PLGWI 2T Supreme M20 Stainless Steel Lifting Point

Pewag

$263.17
(No reviews yet) Write a Review
SKU:
4009936
Availability:
Call to check availability
Weight:
0.60 KGS
Shipping:
Calculated at Checkout

The PLGWI is an lifting point from the pewag winner profilift family.

Specifications
pewag winner profilift gamma inox.Patented comfort and stainless steel.
  • Alignment in load direction possible
  • Temperature range: up to 280°C
  • Stamped with an identification number, the pewag logo and a CE mark
  • Bolt stamped with PW, batch code, thread size, load capacity
  • 100% crack tested
  • Markings for 45° and 60° tilt angle
  • Enhanced corrosion resistance due to material 1.4462 (Duplex)

Specification table

Method of lifting
Number of legs 1 1 2 2 2 2 3+4 3+4 2 3+4
Angle of inclination 0° 90° 0° 90° 0°-45° 45°-60° 0°-45° 45°-60° asymm asymm
Code Thread Torque Working load limit (G)
  [mm] [Nm] [kg]
PLGWI 0,5 t M12 25 1500 500 3000 1000 700 500 1060 750 500 500
PLGWI 1 t M16 50 3000 1000 6000 2000 1400 1000 2100 1500 1000 1000
PLGWI 2 t Supreme M20 115 3800 2000 7600 4000 2800 2000 4200 3000 2000 2000
PLGWI 2 t M20 115 3800 2000 7600 4000 2800 2000 4200 3000 2000 2000
  Code Thread Working a b c d e f n n max Weight
    [mm] load limit [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg/unit]
      [kg]
PLGWI 0,5 t M12 500 30 55 12 30 59 30 18 160 8 0,23
PLGWI 1 t M16 1000 35 64 14 35 67 35 24 160 10 0,36
PLGWI 2 t Supreme M20 2000 40 72 17 40 80 45 30 160 12 0,6
M20 2000 40 72 17 40 80 45 30 160 12
