A RUD PP-B PowerPoint swivel lifting point with UNC thread, featuring a compact bolt-on base and 360° rotating ring, designed for multi-directional industrial lifting applications using imperial threads.

PP-B PowerPoint® - Ring Connection - UNC Thread; Rud

Rud
$214.00 - $953.00
(No reviews yet)
Weight:
0.35 KGS
Current Stock:
Adding to cart… The item has been added
Description

PP-B PowerPoint® - Ring Connection - UNC Thread; Rud



The RUD PP-B PowerPoint (UNC Thread) is a compact, bolt-on swivel lifting point engineered for multi-directional, load-aligned lifting in setups requiring UNC (imperial) thread compatibility. Designed with a 360° rotatable lifting ring, the PP-B automatically aligns with the direction of pull, reducing side load risk and increasing operational safety.

Built from forged high-tensile steel, the PP-B is ideal for permanent or semi-permanent attachment to machinery, lifting fixtures, structural frames, and fabricated components. This model is trusted in sectors such as construction, mining, transport, manufacturing, and maintenance.

Features

  • UNC thread (imperial) – fits American-standard tapped holes

  • 360° rotating lifting ring – aligns naturally with the direction of force

  • Bolt-on design – easy, weld-free installation

  • Forged steel construction – built for strength and safety

  • Load-rated and traceable – marked with WLL and batch number

  • Low-profile, compact design – ideal for tight spaces and assemblies

  • Corrosion-resistant powder-coated finish – suited for tough conditions

  • Reusable and maintenance-free – designed for repeated industrial use

Applications

  • Machinery and equipment lifting – dependable lifting eye for service and transport

  • Steel frame and skid assembly – bolt-on anchor for permanent rigging

  • Mining and heavy industry – tough enough for field use

  • Plant maintenance and servicing – rotating point for angled and vertical lifts

  • Fabrication and industrial assembly – secure lifting during build and positioning

Why Choose the RUD PP-B PowerPoint (UNC Thread)?

  • Compact, bolt-on solution for imperial-threaded applications

  • Allows safe, multi-directional lifting with full rotation

  • Easy to install with no welding required

  • Backed by RUD’s world-class lifting engineering and safety certification

Order Online at WA Lifting Equipment

The RUD PP-B PowerPoint – UNC Thread offers a compact, reliable, and rotatable lifting solution for imperial-threaded industrial applications.
Order now from WA Lifting Equipment for premium RUD gear that meets your lifting needs.

Type WLL (t) A B C D E F Standard F Vario G M T Weight (kg) torque Ref-no. Standard Ref-no. Vario
PP-B-0.63t-M12 0.63 9 65 35 40 36 18 19-145* 41 12 105 0.35 10 Nm 7989522 8600320
PP-B-1.5t-M16 1.5 11 65 35 46 41 25 26-180* 50 16 115 0.6 30 Nm 7989523 8600321
PP-B-2.5t-M20 2.5 13 74 40 55 55 30 31-200 61 20 135 1.1 70 Nm 7989081 8600302
PP-B-4t-M24 4 16 95 45 78 70 36 37-255* 77 24 172 2.4 150 Nm 7989082 8600323
PP-B-5t-M30 5 19 130 60 95 85 45 46-330 93 30 223 5.2 225 Nm 7989524 8600324
PP-B-8t-M36 8 24 140 65 100 90 54 55-300 102 36 242 6.3 410 Nm 7989083 8600305
