PW 6 G10 Eye Shortening Hook

Pewag

$11.80

(No reviews yet) Write a Review

Current Stock:

Quantity:

Thanks to the special design of the chain contact area, this standard shortening hook ensures optimal interaction between chain and hook.

Heavy-duty with a twist.

Even when shortened, the load capacity is not reduced
Suitable for use with Connex and the welded system and can also be retrofitted
It complies with EN 1677-1 with the mechanical values for G10 and comes with CE-marking

Code	Working load limit	e	b	d1	d2	g	Weight
	[kg]	[mm]	[mm]	[mm]	[mm]	[mm]	[kg/pc.]
PW 5	1000	47	40	11	9	7	0,16
PW 6	1400	50	44	12	9	7	0,16
PW 7/8	2500	65	57	16	12	9	0,38
PW 10	4000	77	77	20	14	12	0,72
PW 13	6700	101	92	26	19	15	1,56
PW 16	10000	121	113	32	23	19	2,67
PW 19/20	16000	151	150	36	27	25	6,16
PW 22	19000	170	165	42	31	27	8,3
PW 26	26500	201	195	50	37	32	13,65
PW 32	40000	243	242	60	43	38	25
