A RUD RS Eye Bolt with UNC thread, forged from high-tensile steel and designed for safe vertical lifting, featuring a classic round eye and imperial-threaded shank.

RS / Eye bolt UNC thread

Rud
$140.00 - $327.00
(No reviews yet)
Weight:
0.10 KGS
Current Stock:
Adding to cart… The item has been added
Description

Description

The RUD RS Eye Bolt (UNC Thread) is a simple, strong, and load-rated lifting point designed for vertical lifting applications using imperial-threaded holes. Forged from high-strength steel and precision-machined for reliability, the RS is ideal for securing machinery, structural components, and loads where a traditional eye bolt is required.

Its smooth circular eye is compatible with slings, hooks, and shackles, while the UNC thread makes it suitable for installations following North American or imperial standards.

Features

  • UNC thread (imperial) – ideal for standard American-threaded components

  • Forged steel construction – durable and designed for lifting applications

  • Load-rated for vertical lifts – ensures safety and reliability

  • Smooth round eye – accommodates common lifting gear

  • Clearly marked with WLL and batch number – for traceability

  • Corrosion-resistant coating – suitable for industrial use

  • Simple and effective design – easy to install and remove

Applications

  • Vertical lifting of machinery and fabricated parts

  • Securing equipment for transport

  • Industrial and maintenance rigging

  • Fabrication and workshop setups

  • Installations requiring imperial thread compatibility

Why Choose the RUD RS Eye Bolt (UNC Thread)?

  • Reliable forged construction for secure vertical lifting

  • Compatible with imperial (UNC) tapped holes

  • Load-rated and traceable for safety assurance

  • Built by RUD – trusted worldwide for lifting hardware and engineering excellence

Order Online at WA Lifting Equipment

The RUD RS Eye Bolt – UNC Thread is your go-to solution for safe, straightforward, and certified vertical lifting in imperial-threaded applications.
Order online today from WA Lifting Equipment and rely on RUD quality where it counts.

Type WLL (t) A B C D E F T Weight (kg) Ref.-No.
RS-1/4"-20UNC 0.1 12 11 10 25 25 1/4" 35 0.1 61401
RS-5/16"-18UNC 0.2 12 11 10 25 25 5/16" 35 0.1 61402
RS-3/8"-16UNC 0.25 15 11 10 25 25 3/8" 35 0.1 56397
RS-1/2"-13UNC 0.4 18 13 12 30 30 1/2" 41 0.2 56398
RS-9/16"-12UNC 0.75 21 15 14 35 35 9/16" 48 0.25 56403
RS-5/8"-11UNC 1 24 15 14 35 35 5/8" 48 0.3 56404
RS-3/4"-10UNC 1.2 30 17 16 40 40 3/4" 55 0.35 57205
RS-7/8"-9UNC 1.5 30 17 16 40 40 7/8" 55 0.45 56407
RS-1"-8UNC 2 36 21 20 50 50 1" 70 0.7 56408
RS-1 1/8"-7UNC 2.5 45 26 24 60 60 1 1/8" 85 1.6 57471
RS-1 1/4"-7UNC 3 45 26 24 60 60 1 1/4" 85 1.6 56409
RS-1 1/2"-6UNC 4 54 33 38 90 100 1 1/2" 130 6 56954
RS-1 3/4"-5UNC 6 53 43 38 90 100 1 3/4" 130 6.2 56955
RS-2"-4.5UNC 8 68 43 38 90 100 2" 130 6.4 56956
