Spread Anchor 10T 60x300mm with a robust flared foot and grooved shaft—engineered for lifting large, heavy precast concrete components up to 10 tonnes safely and securely.

Spread Anchor 10T 60x300mm

Austlift
SKU:
739030
Availability:
Usually ship within 24-48 hours
$48.60
(No reviews yet)
Weight:
2.50 KGS
Current Stock:
Adding to cart… The item has been added
Description

Description:
The Spread Anchor 10T 60x300mm is purpose-built for the heaviest lifting applications in precast construction. With a 60mm diameter and 300mm shaft length, this anchor provides deep embedment and superior load transfer—ensuring safe and stable lifting of precast elements up to 10 tonnes.

Its wide flared foot and grooved shaft deliver outstanding anchorage in concrete, making it ideal for bridge segments, foundation panels, large tanks, and structural blocks. Fully compatible with heavy-duty ring clutch systems and recess formers, this anchor is trusted by professionals in civil, commercial, and infrastructure construction.

Features:

  • 10-tonne Working Load Limit

  • 60x300mm shaft for solid embedment

  • Wide flared foot for strong concrete anchorage

  • Grooved shaft enhances bonding and load transfer

  • Suitable for vertical and angled lifts (refer to technical data)

  • Compatible with heavy-duty lifting clutches and formers

Applications:

  • Precast bridge segments and large structural components

  • Heavy concrete foundation panels

  • Tanks, culverts, and vaults

  • Infrastructure and civil engineering projects

  • Precast yards handling high-mass elements

Why Choose the Spread Anchor 10T 60x300mm?

  • Built for extreme loads and thick precast elements

  • Provides safe, reliable lifting in heavy-duty environments

  • Reusable with proper care and handling

  • Fully integrates with standard precast lifting systems

Call to Action (Order Online):
Take on your heaviest lifting challenges with the Spread Anchor 10T 60x300mm.
Order online now from WA Lifting Equipment—your trusted partner in certified high-capacity precast lifting solutions.
