Spread Anchor 4T 40x320mm featuring an extended grooved shaft and flared foot—designed for secure, deep embedment in thick precast concrete panels and components.

Spread Anchor 4T 40x320mm

Austlift
SKU:
734032
Availability:
Usually ship within 24-48 hours
$28.30
(No reviews yet)
Weight:
1.10 KGS
Current Stock:
Adding to cart… The item has been added
Description

Description:
The Spread Anchor 4T 40x320mm is a heavy-duty lifting anchor specifically designed for thick and high-strength precast concrete applications. With an extended 320mm shaft and 4-tonne load rating, it offers deeper embedment and enhanced lifting stability—ideal for large, heavy structural elements.

Its flared foot ensures solid anchorage within the concrete, while the grooved shaft improves mechanical bonding. Compatible with standard ring clutch systems and recess formers, this anchor is perfect for lifting infrastructure components, commercial panels, and civil precast units with maximum safety.

Features:

  • 4-tonne Working Load Limit

  • 40x320mm shaft for extra-deep embedment

  • Flared foot design for superior concrete anchorage

  • Grooved shaft for secure concrete bonding

  • Suitable for vertical and angled lifting (refer to load charts)

  • Fully compatible with standard clutches and formers

Applications:

  • Thick precast wall and floor panels

  • Utility tanks, vaults, and drainage pits

  • Bridge and infrastructure components

  • Structural blocks and heavy civil works

  • Precast yards producing high-mass elements

Why Choose the Spread Anchor 4T 40x320mm?

  • Ideal for lifting from deep-set positions in thick concrete

  • Designed for safe handling of heavier loads

  • Reusable under proper site procedures

  • Compatible with common industry lifting gear

Call to Action (Order Online):
Tackle your toughest lifts with the Spread Anchor 4T 40x320mm.
Order online now at WA Lifting Equipment—your leading source for certified concrete lifting systems that meet the highest demands.
