VLW 1-10 G10 Oversized Master Link

VLW 1-10 G10 Oversized Master Link

Pewag

$150.64
(No reviews yet) Write a Review
SKU:
4014237
Availability:
Call to check availability
Weight:
7.70 KGS
Shipping:
Calculated at Checkout

Master link assembly for I-leg chain slings in assembled or welded systems.

Specifications
Compelling simplicity.
  • Complies with EN 1677-4 and the mechanical values for G10
  • Extra-large rings make this master link assembly the perfect partner for crane hooks according to DIN 15401 up to no. 25 and according to DIN 15402 up to no. 32
  • A flattened section on the transition links open up additional, universal connection possibilities (measurements can be obtained from the product “BW”)
  • CE-marking, BG-approval and a full operating manual

Specification table

  Code Consisting of Working load limit Fits on single hook acc. DIN 15401 no. Fits on single hook acc. DIN 15401 no.
      0°-45°
      [kg]
VLW 1-19/22 LW 40 19000 25 32
VLW 1-10 LW 27 + BW 16 4000 25 32
VLW 1-13 LW 27 6700 25 32
VLW 1-16 LW 32 10000 25 32
VLW 1-6/7/8 LW 22 + BW 13 2500 25 32
    Code e d t w s d1 t1 w1 Weight
      [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg/pc.]
VLW 1-19/22 340 40 340 180 29 - - - 10
VLW 1-10 410 27 340 180 20 17 70 34 4,76
VLW 1-13 340 27 340 180 20 - - - 4,4
VLW 1-16 340 33 340 180 27 - - - 6,7
VLW 1-6/7/8 394 23 340 180 17 13 54 25 3,37
