Pewag Winner G10 Oversize Master Link Assembly to EN 1677-4 with mechanical values for Grade 10.
- For use with 3 and 4 leg chain slings
- Manufactured from special alloy steel
- Proof load tested to 2.5 x WLL
- Fatigue tested to 1.5 x WLL for 20,000 cycles
- 100% Magnaflux crack detected
- Powder coated
Operating temperature range from -40°C to 380°C (up to 200°C without reduction in WLL).
Fully compliant for use in chain slings certified to EN818-4. Only components manufactured to EN1677 meet with the requirements of this standard.
| Code | Consisting of | Load capacity 0°-45° [tonnes] | Used up to single hook | e [mm] | d [mm] | t [mm] | w [mm] | Weight [kg/pc] |
| VSAW2-10/13 / 4-10 | SAW32 + 2 BW20 | 9.50 | Nr. 50 | 585 | 33 | 500 | 250 | 10.69 |
| VSAW2-16 / 4-13 | SAW40 + 2 BW22 | 14.00 | Nr. 50 | 575 | 40 | 460 | 250 | 15.45 |
| VSAW2-19/20 / 4-16 | SAW45 + 2 BW26 | 21.20 | Nr. 50 | 640 | 45 | 500 | 250 | 21.65 |
| VSAW2-22 / 4-19/20 | SAW50 + 2 BW32 | 30.00 | Nr. 50 | 610 | 50 | 460 | 250 | 27.32 |
| VSAW2-26 / 4-22 | SAW56 + 2 BW32 | 40.00 | Nr. 50 | 610 | 56 | 460 | 250 | 34.30 |
| VSAW2-26 / 4-22 320 | SAW60 + 2 BW32 | 40.00 | Nr. 100 | 950 | 60 | 800 | 320 | 54.32 |
