A RUD VWBG-V swivel lifting ring with metric coarse thread, featuring a 360° rotatable body and 180° pivoting ring, designed for safe, multi-directional lifting in industrial and construction environments.

VWBG-V / Swivel lifting ring metric coarse thread

Rud
$212.00 - $693.00
(No reviews yet)
Weight:
0.18 KGS
Current Stock:
Adding to cart… The item has been added
Description

Description

The RUD VWBG-V Swivel Lifting Ring (Metric Coarse Thread) is a fully rotatable and pivoting lifting point designed to support complex lifting operations in demanding industrial applications. With a 360° rotating body and a 180° pivoting ring, this lifting point automatically aligns with the direction of the load, ensuring optimal force distribution and enhanced safety during lifting, turning, or tilting.

Manufactured from forged, high-tensile steel and clearly marked with WLL (Working

Limit), the VWBG-V is precision-engineered for use on machinery, fabricated compone

nts, and heavy-duty assemblies that require a multi-directional, load-rated attachment point.

Features

  • Metric coarse thread for secure and standardised installation

  • 360° rotating body with 180° pivoting ring for multi-directional alignment

  • Load-optimised design minimises stress on the lifting bolt

  • Forged high-strength steel – durable and reliable under demanding loads

  • Clearly marked with WLL and batch number for full traceability

  • Powder-coated for corrosion resistance and visibility

  • Compatible with lifting slings, hooks, and rigging hardware

  • Designed for repeated, safe use in harsh working environments

Applications

  • Lifting heavy equipment and machinery – Perfect for off-centre or angled lifts

  • Steel fabrication and rigging – Multi-directional lifting of large assemblies

  • Transport and load turning – Allows for safe rotation and tilting during handling

  • Construction and infrastructure projects – Secure and flexible lifting point

  • Maintenance and servicing – Ideal for rotating components during installation/removal

Why Choose the RUD VWBG-V Swivel Lifting Ring?

  • True multi-directional functionality – Adapts to the angle of the load

  • Proven RUD engineering – Trusted worldwide for lifting safety and innovation

  • Versatile and powerful – Suitable for lifting, tilting, and rotating loads

  • Precision forged and tested – Reliable under heavy and repetitive use

Order Online at WA Lifting Equipment

The RUD VWBG-V Swivel Lifting Ring (Metric Coarse Thread) offers unmatched versatility and strength for complex lifting applications. Engineered for precision and safety—order now at WA Lifting Equipment.

Type WLL [t] A [mm] B [mm] C [mm] D [mm] Fstand [mm] Fmax [mm] G [mm] K [mm] M [mm] T [mm] X [mm] weight [kg/pc.] Bolting Torque [Nm] Ref.-No. Stand. Ref.-No. Vario with washer and nut
VWBG-V 0.3 M8 0.3 (0.4) 8 31 29 30 13 102 36 28 8 76 18 0.25 10 7103720 8600330
VWBG-V 0.45 M10 0.45 (0.6) 8 31 29 36 17 122 38 30 10 78 19 0.3 10 7103715 8600331
VWBG-V 0.6 M12 0.6 (0.75) 10 49 35 42 21 140 47 36 12 107 19 0.4 10 7100180 8600332
VWBG-V 1.0 M14 1.0 (1.25) 13 45 42 41 25 160 56 46 14 121 25 1 25 7100430 8600337
VWBG-V 1.3 M16 1.3 (1.5) 13 46 38 41 25 160 56 46 16 137 28 1.1 30 – 8600333
VWBG-V 1.8 M18 1.8 (2.0) 13 54 35 46 27 83 67 55 18 137 - 1.5 50 – 8600338
VWBG-V 2.0 M20 2.0 (2.5) 13 54 35 50 33 223 67 55 20 157 30 1.4 100 7100800 8600335
VWBG-V 2.0 M22 2.0 (2.5) 13 54 35 53 33 94 64 54 22 137 22 1.5 120 – 8600334
VWBG-V 3.5 M24 3.5 (4.0) 18 66 40 70 40 255 88 70 24 180 25 2.6 150 7100640 8600336
VWBG-V 3.5 M27 3.5 (4.0) 18 66 40 70 40 92 80 70 27 173 25 2.9 200 – 8600339
VWBG-V 5.0 M30 5.0 (6.0) 22 90 50 90 50 330 106 85 30 221 32 5.5 225 7100650 8600336
